k8s-1.29.0部署

基本环境准备

系统环境信息配置

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
# 1. 配置hosts
hostnamectl set-hostname control-plane
exec bash

# 2. 配置hosts
cat <<'EOF' | tee -a /etc/hosts
192.168.1.237 control-plane
EOF

# 3. 转发 IPv4 并让 iptables 看到桥接流量
cat <<'EOF' | sudo tee /etc/modules-load.d/k8s.conf
overlay
br_netfilter
EOF

sudo modprobe overlay
sudo modprobe br_netfilter

# 4. 确认 br_netfilter 和 overlay 模块被加载：
lsmod | grep br_netfilter
lsmod | grep overlay


# 5. 设置所需的 sysctl 参数，参数在重新启动后保持不变
cat <<'EOF' | sudo tee /etc/sysctl.d/k8s.conf
net.bridge.bridge-nf-call-iptables  = 1
net.bridge.bridge-nf-call-ip6tables = 1
net.ipv4.ip_forward                 = 1
EOF

# 6. 应用 sysctl 参数而不重新启动
sudo sysctl --system

# 验证net.bridge.bridge-nf-call-iptables, net.bridge.bridge-nf-call-ip6tables , net.ipv4.ip_forward 系统变量设置为1
sysctl net.bridge.bridge-nf-call-iptables net.bridge.bridge-nf-call-ip6tables net.ipv4.ip_forward

# 7. 关闭swap
swapoff -a
sed -i '/swap/s/.*/#&/g' /etc/fstab


# 8. 关闭selinux
sudo setenforce 0
sudo sed -i 's/^SELINUX=enforcing$/SELINUX=disabled/' /etc/selinux/config

# 9. 安装chrony同步时间
yum install chrony -y
systemctl enable --now chronyd
chronyc sources

安装ipvs用于做代理

https://github.com/kubernetes/kubernetes/blob/master/pkg/proxy/ipvs/README.md#run-kube-proxy-in-ipvs-mode

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
cat <<'EOF' | tee /etc/sysconfig/modules/ipvs.modules
#!/bin/bash
modprobe -- ip_vs
modprobe -- ip_vs_rr
modprobe -- ip_vs_wrr
modprobe -- ip_vs_sh
modprobe -- nf_conntrack_ipv4
EOF

chmod 755 /etc/sysconfig/modules/ipvs.modules && bash /etc/sysconfig/modules/ipvs.modules && lsmod | grep -e ip_vs -e nf_conntrack_ipv4

yum -y install ipset ipvsadm

# 查看安装的版本
[root@control-plane calico]# yum -y install ipset ipvsadm
Package ipset-7.1-1.el7.x86_64 already installed and latest version
Package ipvsadm-1.27-8.el7.x86_64 already installed and latest version

安装kubeadm

官方(推荐)

官方才是最新的
https://kubernetes.io/zh-cn/docs/setup/production-environment/tools/kubeadm/install-kubeadm/

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23

cat <<'EOF' | sudo tee /etc/yum.repos.d/kubernetes.repo
[kubernetes]
name=Kubernetes
baseurl=https://pkgs.k8s.io/core:/stable:/v1.29/rpm/
enabled=1
gpgcheck=1
gpgkey=https://pkgs.k8s.io/core:/stable:/v1.29/rpm/repodata/repomd.xml.key
exclude=kubelet kubeadm kubectl cri-tools kubernetes-cni
EOF

sudo yum install -y kubelet kubeadm kubectl --disableexcludes=kubernetes
sudo systemctl enable --now kubelet

# kubelet 现在每隔几秒就会重启，因为它陷入了一个等待 kubeadm 指令的死循环。

# 查看安装版本
[root@control-plane ~]# rpm -qa | grep -E "kube"
kubernetes-cni-1.3.0-150500.1.1.x86_64
kubelet-1.29.0-150500.1.1.x86_64
kubectl-1.29.0-150500.1.1.x86_64
kubeadm-1.29.0-150500.1.1.x86_64

阿里云

https://developer.aliyun.com/mirror/kubernetes?spm=a2c6h.13651102.0.0.560a1b11gYpsH1
2024-01-02, 官方最新1.29.0, 阿里云只有1.28.2

1
2
3
4
5
6
7
8
9
10
11
12
13

cat <<'EOF' > /etc/yum.repos.d/kubernetes.repo
[kubernetes]
name=Kubernetes
baseurl=https://mirrors.aliyun.com/kubernetes/yum/repos/kubernetes-el7-x86_64/
enabled=1
gpgcheck=1
repo_gpgcheck=1
gpgkey=https://mirrors.aliyun.com/kubernetes/yum/doc/yum-key.gpg https://mirrors.aliyun.com/kubernetes/yum/doc/rpm-package-key.gpg
EOF

yum install -y kubelet kubeadm kubectl
systemctl enable kubelet && systemctl start kubelet

清华

https://mirrors.tuna.tsinghua.edu.cn/help/kubernetes/
2024-01-02, 官方最新1.29.0, 清华只有1.28.2

1
2
3
4
5
6
7
8
9
10
cat <<'EOF' | tee /etc/yum.repos.d/kubernetes.repo

[kubernetes]
name=kubernetes
baseurl=https://mirrors.tuna.tsinghua.edu.cn/kubernetes/yum/repos/kubernetes-el7-$basearch
enabled=1
gpgcheck=0
EOF

yum install -y kubelet kubeadm kubectl --disableexcludes=kubernetes

命令补全

1
2
3
4
5
6
yum -y install bash-completion
# type _init_completion测试成功则说明bash-completion已经安装且正常生效了
kubectl completion bash > /etc/bash_completion.d/kubectl
kubeadm completion bash > /etc/bash_completion.d/kubeadm
# 使其在当前bash生效
exec bash

配置crictl

CRI为docker

1
2
3
4
5
6
7
8
# 参考： https://github.com/kubernetes-sigs/cri-tools/blob/master/docs/crictl.md
cat <<'EOF' | tee /etc/crictl.yaml
runtime-endpoint: unix:///var/run/cri-dockerd.sock
image-endpoint: unix:///var/run/cri-dockerd.sock
timeout: 2
debug: false
pull-image-on-create: false
EOF

CRI为containerd

1
2
3
4
5
6
7
8
9
# 参考： https://github.com/kubernetes-sigs/cri-tools/blob/master/docs/crictl.md
cat <<'EOF' | tee /etc/crictl.yaml
runtime-endpoint: unix:///var/run/containerd/containerd.sock
image-endpoint: unix:///var/run/containerd/containerd.sock
timeout: 2
debug: false
pull-image-on-create: false
EOF

基于docker

安装docker

官方

https://docs.docker.com/engine/install/centos/

1
2
3
4
sudo yum install -y yum-utils
sudo yum-config-manager --add-repo https://download.docker.com/linux/centos/docker-ce.repo
# sudo yum install docker-ce docker-ce-cli containerd.io docker-buildx-plugin docker-compose-plugin
sudo yum -y install docker-ce docker-ce-cli docker-buildx-plugin docker-compose-plugin

阿里云源

https://developer.aliyun.com/mirror/docker-ce?spm=a2c6h.13651102.0.0.57e31b11KIc1Rx

1
2
3
4
5
6
7
8
9
10
11
# step 1: 安装必要的一些系统工具
sudo yum install -y yum-utils device-mapper-persistent-data lvm2
# Step 2: 添加软件源信息
sudo yum-config-manager --add-repo https://mirrors.aliyun.com/docker-ce/linux/centos/docker-ce.repo
# Step 3
sudo sed -i 's+download.docker.com+mirrors.aliyun.com/docker-ce+' /etc/yum.repos.d/docker-ce.repo
# Step 4: 更新并安装Docker-CE
sudo yum makecache fast
sudo yum -y install docker-ce
# Step 4: 开启Docker服务
sudo service docker start

清华源

https://mirrors.tuna.tsinghua.edu.cn/help/docker-ce/

1
2
3
4
5
yum install -y yum-utils
yum-config-manager --add-repo https://download.docker.com/linux/centos/docker-ce.repo
sed -i 's+https://download.docker.com+https://mirrors.tuna.tsinghua.edu.cn/docker-ce+' /etc/yum.repos.d/docker-ce.repo
# yum install docker-ce docker-ce-cli containerd.io docker-buildx-plugin docker-compose-plugin
sudo yum -y install docker-ce docker-ce-cli docker-buildx-plugin docker-compose-plugin

配置docker

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
sudo mkdir /etc/docker
cat <<'EOF' | sudo tee /etc/docker/daemon.json
{
  "registry-mirrors": [
     "https://ywuql7hg.mirror.aliyuncs.com",
     "https://docker.mirrors.ustc.edu.cn",
     "https://reg-mirror.qiniu.com",
     "http://hub-mirror.c.163.com"
  ],

  "exec-opts": ["native.cgroupdriver=systemd"],
  "log-driver": "json-file",
  "log-opts": {
    "max-size": "100m",
    "max-file":"3"
  }
}
EOF

启动docker

1
2
3
4
5
6
7
8
9
10
11
12
# 查看版本
[root@centos7 init-install]# rpm -qa | grep docker
docker-ce-rootless-extras-24.0.7-1.el7.x86_64
docker-ce-cli-24.0.7-1.el7.x86_64
docker-ce-24.0.7-1.el7.x86_64
cri-dockerd-0.3.8-3.el7.x86_64
docker-buildx-plugin-0.11.2-1.el7.x86_64
docker-compose-plugin-2.21.0-1.el7.x86_64

# 启动
systemctl enable --now docker

安装cri-docker

自 1.24 版起，Dockershim 已从 Kubernetes 项目中移除。阅读 Dockershim 移除的常见问题了解更多详情。
高版本需要安装cri-dockerd,

github地址: https://github.com/Mirantis/cri-dockerd

1
2
3
4
# 安装
rpm -ivh https://github.com/Mirantis/cri-dockerd/releases/download/v0.3.9/cri-dockerd-0.3.9-3.el7.x86_64.rpm
# 修改配置启动脚本, 不然默认拉取的镜像是3.6的
sed -i 's#cri-dockerd --container-runtime-endpoint#cri-dockerd --pod-infra-container-image registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/pause:3.9 --container-runtime-endpoint#g'  /usr/lib/systemd/system/cri-docker.service

启动cri-docker

1
systemctl enable --now cri-docker

部署k8s

查看需要下载的镜像

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
[root@centos7 ~]# kubeadm config images list
registry.k8s.io/kube-apiserver:v1.29.0
registry.k8s.io/kube-controller-manager:v1.29.0
registry.k8s.io/kube-scheduler:v1.29.0
registry.k8s.io/kube-proxy:v1.29.0
registry.k8s.io/coredns/coredns:v1.11.1
registry.k8s.io/pause:3.9
registry.k8s.io/etcd:3.5.10-0

# 通过google云下载并推送到自己的阿里云仓库, !!!������������需要先登录阿里云的镜像仓库
while read line;do
    img_url=$(echo $line | awk -F '[/:]' '{print $1}')
    img_name=$(echo $line | awk -F '[/:]' '{print $2}')
    img_ver=$(echo $line | awk -F '[/:]' '{print $3}')
    src_img=${img_url}/${img_name}:${img_ver}
    dst_img=registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/${img_name}:${img_ver}
    docker pull $src_img
    docker tag $src_img $dst_img
    echo docker push $dst_img
    docker push $dst_img
done < kubeadm config images list

kubeadm初始化配置

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
# 打印默认的init信息并保存.
mkdir -p /data/k8s/init-install
cd /data/k8s/init-install
kubeadm config print init-defaults > kubeadm.yaml

# 修改信息 kubeadm.yaml如下:
apiVersion: kubeadm.k8s.io/v1beta3
bootstrapTokens:
- groups:
  - system:bootstrappers:kubeadm:default-node-token
  token: abcdef.0123456789abcdef
  ttl: 24h0m0s
  usages:
  - signing
  - authentication
kind: InitConfiguration
localAPIEndpoint:
  advertiseAddress: 192.168.1.237          # 修改为控制平面IP
  bindPort: 6443
nodeRegistration:
  # criSocket: unix:///var/run/containerd/containerd.sock
  criSocket: unix:///var/run/cri-dockerd.sock    # 修改为cri-dockerd的sock
  imagePullPolicy: IfNotPresent
  name: control-plane          # node修改为control-plane
  taints:

---
apiServer:
  timeoutForControlPlane: 4m0s
apiVersion: kubeadm.k8s.io/v1beta3
certificatesDir: /etc/kubernetes/pki
clusterName: kubernetes
controllerManager: {}
dns: {}
etcd:
  local:
    dataDir: /var/lib/etcd
#imageRepository: registry.k8s.io
imageRepository: registry.cn-shenzhen.aliyuncs.com/only_wild_weeds        # 修改为自己的镜像源
kind: ClusterConfiguration
kubernetesVersion: 1.29.0                  # kubeadm是1.29.0, 输出安装的版本就不用改了, 如果需要改,
# 参考
# - Kubernetes [版本与版本间的偏差策略](https://kubernetes.io/zh-cn/releases/version-skew-policy/)
# - kubeadm 特定的[版本偏差策略](https://kubernetes.io/zh-cn/docs/setup/production-environment/tools/kubeadm/create-cluster-kubeadm/#version-skew-policy)
networking:
  dnsDomain: cluster.local
  serviceSubnet: 10.96.0.0/12
  podSubnet: 10.244.0.0/16 # 指定pod的IP地址.
scheduler: {}
#### 配置kube-proxy 模式,
# 参考: https://github.com/kubernetes/kubernetes/blob/master/pkg/proxy/ipvs/README.md#run-kube-proxy-in-ipvs-mode
---
apiVersion: kubeproxy.config.k8s.io/v1alpha1
kind: KubeProxyConfiguration
mode: ipvs

下载初始化需要的镜像

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23

# 查看初始化需要下载的镜像.
[root@centos7 init-install]# kubeadm config images list --config=kubeadm.yaml
registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/kube-apiserver:v1.29.0
registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/kube-controller-manager:v1.29.0
registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/kube-scheduler:v1.29.0
registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/kube-proxy:v1.29.0
registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/coredns:v1.11.1
registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/pause:3.9
registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/etcd:3.5.10-0


# 手动下载初始化需要的镜像.
[root@centos7 init-install]# kubeadm config images pull --image-repository=registry.cn-shenzhen.aliyuncs.com/only_wild_weeds --cri-socket=unix:///var/run/cri-dockerd.sock  --kubernetes-version=1.29.0
[config/images] Pulled registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/kube-apiserver:v1.29.0
[config/images] Pulled registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/kube-controller-manager:v1.29.0
[config/images] Pulled registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/kube-scheduler:v1.29.0
[config/images] Pulled registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/kube-proxy:v1.29.0
[config/images] Pulled registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/coredns:v1.11.1
[config/images] Pulled registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/pause:3.9
[config/images] Pulled registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/etcd:3.5.10-0


部署

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48

# 使用生成的配置文件初始化(默认是找/var/lib/kubelet/config.yaml)
kubeadm init --config /data/k8s/init-install/kubeadm.yaml

# 报错：最后是因为没有配置cri-dockerd的--pod-infra-container-image 参数, 导致默认下载的是  registry.k8s.io/pause:3.6
kubelet-start] Starting the kubelet
[wait-control-plane] Waiting for the kubelet to boot up the control plane as static Pods from directory "/etc/kubernetes/manifests". This can take up to 4m0s
[kubelet-check] Initial timeout of 40s passed.

Unfortunately, an error has occurred:
	timed out waiting for the condition

This error is likely caused by:
	- The kubelet is not running
	- The kubelet is unhealthy due to a misconfiguration of the node in some way (required cgroups disabled)

If you are on a systemd-powered system, you can try to troubleshoot the error with the following commands:
	- 'systemctl status kubelet'
	- 'journalctl -xeu kubelet'

Additionally, a control plane component may have crashed or exited when started by the container runtime.
To troubleshoot, list all containers using your preferred container runtimes CLI.
Here is one example how you may list all running Kubernetes containers by using crictl:
	- 'crictl --runtime-endpoint unix:///var/run/cri-dockerd.sock ps -a | grep kube | grep -v pause'
	Once you have found the failing container, you can inspect its logs with:
	- 'crictl --runtime-endpoint unix:///var/run/cri-dockerd.sock logs CONTAINERID'
error execution phase wait-control-plane: couldn't initialize a Kubernetes cluster
To see the stack trace of this error execute with --v=5 or higher


# kubelet的日志：
Jan 03 02:17:11 control-plane kubelet[2598]: E0103 02:17:11.964435    2598 remote_runtime.go:193] "RunPodSandbox from runtime service failed" err="rpc error: code = Unknown desc = failed pulling image \"registry.k8s.io/pause:3.6\": Error response from daemon: Head \"https://asia-east1-docker.pkg.dev/v2/k8s-artifacts-prod/images/pause/manifests/3.6\": dial tcp 108.177.97.82:443: i/o timeout"

# 查看kubelet的配置, 明明指定的基础镜像是: registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/pause:3.9, 但它还是取下载3.6, 有毒
# cat /usr/lib/systemd/system/kubelet.service.d/10-kubeadm.conf
# cat /var/lib/kubelet/kubeadm-flags.env
KUBELET_KUBEADM_ARGS="--container-runtime-endpoint=unix:///var/run/cri-dockerd.sock --hostname-override=control-plane --pod-infra-container-image=registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/pause:3.9"

# 尝试手动下载这个镜像,
crictl pull registry.k8s.io/pause:3.6

# 报另一个错了, 这事因为没有部署cni导致的, 部署cni速度很慢.
Jan 03 02:30:45 control-plane kubelet[3726]: E0103 02:30:45.842118    3726 kubelet.go:2892] "Container runtime network not ready" networkReady="NetworkReady=false reason:NetworkPluginNotReady message:docker: network plugin is not ready: cni config uninitialized"


# 没有找到和k8s版本对应关系， 可能和这个有关系,  应该是配套cri没有升级上来导致的, 先这样吧, MD, 搞几个小时了.
https://github.com/Mirantis/cri-dockerd/blob/master/README.md#to-use-with-kubernetes

去掉control-plane的污点

1
2
3
4
# 默认情况下，出于安全原因，你的集群不会在控制平面节点上调度 Pod。
# 如果你希望能够在单机 Kubernetes 集群等控制平面节点上调度 Pod，请运行：
kubectl taint nodes --all node-role.kubernetes.io/control-plane-

卸载reset

1
2
3
4
5
6
7
8
kubeadm reset -f --cri-socket=unix:///var/run/cri-dockerd.sock
kubeadm reset -f --cri-socket=unix:///var/run/containerd/containerd.sock

iptables -F && iptables -t nat -F && iptables -t mangle -F && iptables -X
ipvsadm -C
rm -rf /etc/cni/net.d $HOME/.kube/config

systemctl restart kubelet

CNI部署后检查信息

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
[root@control-plane calico]# kubectl get no -o wide
NAME            STATUS   ROLES           AGE   VERSION   INTERNAL-IP     EXTERNAL-IP   OS-IMAGE                KERNEL-VERSION                 CONTAINER-RUNTIME
control-plane   Ready    control-plane   34m   v1.29.0   192.168.1.237   <none>        CentOS Linux 7 (Core)   3.10.0-1160.105.1.el7.x86_64   docker://24.0.7

[root@control-plane calico]# kubectl get po --all-namespaces
NAMESPACE          NAME                                       READY   STATUS    RESTARTS   AGE
calico-apiserver   calico-apiserver-6f9c7fb8c9-qcmhl          1/1     Running   0          12m
calico-apiserver   calico-apiserver-6f9c7fb8c9-x5w49          1/1     Running   0          12m
calico-system      calico-kube-controllers-67d65977d7-x54xm   1/1     Running   0          24m
calico-system      calico-node-4qmwf                          1/1     Running   0          22m
calico-system      calico-typha-bbc495d89-gnmcg               1/1     Running   0          24m
calico-system      csi-node-driver-f8p9k                      2/2     Running   0          24m
kube-system        coredns-76cdc8f664-4kt62                   1/1     Running   0          33m
kube-system        coredns-76cdc8f664-dvbdr                   1/1     Running   0          33m
kube-system        etcd-control-plane                         1/1     Running   0          33m
kube-system        kube-apiserver-control-plane               1/1     Running   0          33m
kube-system        kube-controller-manager-control-plane      1/1     Running   0          33m
kube-system        kube-proxy-lg2kb                           1/1     Running   0          33m
kube-system        kube-scheduler-control-plane               1/1     Running   0          33m
tigera-operator    tigera-operator-55585899bf-qfnfg           1/1     Running   0          31m
[root@control-plane calico]# docker images
REPOSITORY                                                                  TAG        IMAGE ID       CREATED         SIZE
quay.io/tigera/operator                                                     v1.32.3    7bc79e0d3be4   2 weeks ago     69.6MB
calico/typha                                                                v3.27.0    b33768e0da1f   2 weeks ago     68.3MB
calico/kube-controllers                                                     v3.27.0    4e87edec0297   2 weeks ago     75.5MB
calico/apiserver                                                            v3.27.0    848c5b919e8d   2 weeks ago     93.9MB
calico/cni                                                                  v3.27.0    8e8d96a874c0   2 weeks ago     211MB
calico/node-driver-registrar                                                v3.27.0    d36ef67f7b24   2 weeks ago     22.5MB
calico/csi                                                                  v3.27.0    91c1c91da760   2 weeks ago     17.4MB
calico/pod2daemon-flexvol                                                   v3.27.0    6506d2e0be2d   2 weeks ago     15.4MB
calico/node                                                                 v3.27.0    1843802b91be   2 weeks ago     340MB
registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/kube-controller-manager   v1.29.0    0824682bcdc8   3 weeks ago     122MB
registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/kube-apiserver            v1.29.0    1443a367b16d   3 weeks ago     127MB
registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/kube-scheduler            v1.29.0    7ace497ddb8e   3 weeks ago     59.5MB
registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/kube-proxy                v1.29.0    98262743b26f   3 weeks ago     82.2MB
registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/etcd                      3.5.10-0   a0eed15eed44   2 months ago    148MB
registry.aliyuncs.com/google_containers/coredns                             v1.11.1    cbb01a7bd410   4 months ago    59.8MB
registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/coredns                   v1.11.1    cbb01a7bd410   4 months ago    59.8MB
registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/pause                     3.9        e6f181688397   14 months ago   744kB


基于containerd

github安装文档： https://github.com/containerd/containerd/blob/main/docs/getting-started.md
版本兼容性：https://github.com/containerd/containerd/blob/main/RELEASES.md#kubernetes-support

安装containerd

1
2
3
4
5
6
7
8
9
10
11
12
# 参考: https://docs.docker.com/engine/install/centos/
# 安装containerd
sudo yum install -y yum-utils
sudo yum-config-manager --add-repo https://download.docker.com/linux/centos/docker-ce.repo

# 安装最新版本
sudo yum install -y docker-ce docker-ce-cli containerd.io docker-buildx-plugin docker-compose-plugin

# 查看 containerd版本
rpm -qa | grep containerd
containerd.io-1.6.26-3.1.el7.x86_64

配置config.toml

config.toml参数详解: https://github.com/containerd/containerd/blob/main/docs/man/containerd-config.toml.5.md

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
# 备份原配置文件
cp /etc/containerd/config.toml{,_bak}
# 重新生成配置文件
containerd config default > /etc/containerd/config.toml

# 修改配置文件
cat /etc/containerd/config.toml
#
disabled_plugins = []
imports = []
oom_score = 0
plugin_dir = ""
required_plugins = []
root = "/var/lib/containerd"
state = "/run/containerd"
temp = ""
version = 2

[cgroup]
  path = ""

[debug]
  address = ""
  format = ""
  gid = 0
  level = ""
  uid = 0

[grpc]
  address = "/run/containerd/containerd.sock"
  gid = 0
  max_recv_message_size = 16777216
  max_send_message_size = 16777216
  tcp_address = ""
  tcp_tls_ca = ""
  tcp_tls_cert = ""
  tcp_tls_key = ""
  uid = 0

[metrics]
  address = ""
  grpc_histogram = false

[plugins]

  [plugins."io.containerd.gc.v1.scheduler"]
    deletion_threshold = 0
    mutation_threshold = 100
    pause_threshold = 0.02
    schedule_delay = "0s"
    startup_delay = "100ms"

  [plugins."io.containerd.grpc.v1.cri"]
    device_ownership_from_security_context = false
    disable_apparmor = false
    disable_cgroup = false
    disable_hugetlb_controller = true
    disable_proc_mount = false
    disable_tcp_service = true
    enable_selinux = false
    enable_tls_streaming = false
    enable_unprivileged_icmp = false
    enable_unprivileged_ports = false
    ignore_image_defined_volumes = false
    max_concurrent_downloads = 3
    max_container_log_line_size = 16384
    netns_mounts_under_state_dir = false
    restrict_oom_score_adj = false
    #sandbox_image = "registry.k8s.io/pause:3.6"
    sandbox_image = "registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/pause:3.9"       # 修改这
    selinux_category_range = 1024
    stats_collect_period = 10
    stream_idle_timeout = "4h0m0s"
    stream_server_address = "127.0.0.1"
    stream_server_port = "0"
    systemd_cgroup = false
    tolerate_missing_hugetlb_controller = true
    unset_seccomp_profile = ""

    [plugins."io.containerd.grpc.v1.cri".cni]
      bin_dir = "/opt/cni/bin"
      conf_dir = "/etc/cni/net.d"
      conf_template = ""
      ip_pref = ""
      max_conf_num = 1

    [plugins."io.containerd.grpc.v1.cri".containerd]
      default_runtime_name = "runc"
      disable_snapshot_annotations = true
      discard_unpacked_layers = false
      ignore_rdt_not_enabled_errors = false
      no_pivot = false
      snapshotter = "overlayfs"

      [plugins."io.containerd.grpc.v1.cri".containerd.default_runtime]
        base_runtime_spec = ""
        cni_conf_dir = ""
        cni_max_conf_num = 0
        container_annotations = []
        pod_annotations = []
        privileged_without_host_devices = false
        runtime_engine = ""
        runtime_path = ""
        runtime_root = ""
        runtime_type = ""

        [plugins."io.containerd.grpc.v1.cri".containerd.default_runtime.options]

      [plugins."io.containerd.grpc.v1.cri".containerd.runtimes]

        [plugins."io.containerd.grpc.v1.cri".containerd.runtimes.runc]
          base_runtime_spec = ""
          cni_conf_dir = ""
          cni_max_conf_num = 0
          container_annotations = []
          pod_annotations = []
          privileged_without_host_devices = false
          runtime_engine = ""
          runtime_path = ""
          runtime_root = ""
          runtime_type = "io.containerd.runc.v2"

          [plugins."io.containerd.grpc.v1.cri".containerd.runtimes.runc.options]
            BinaryName = ""
            CriuImagePath = ""
            CriuPath = ""
            CriuWorkPath = ""
            IoGid = 0
            IoUid = 0
            NoNewKeyring = false
            NoPivotRoot = false
            Root = ""
            ShimCgroup = ""
            # SystemdCgroup = false
            SystemdCgroup = true            # 修改这

      [plugins."io.containerd.grpc.v1.cri".containerd.untrusted_workload_runtime]
        base_runtime_spec = ""
        cni_conf_dir = ""
        cni_max_conf_num = 0
        container_annotations = []
        pod_annotations = []
        privileged_without_host_devices = false
        runtime_engine = ""
        runtime_path = ""
        runtime_root = ""
        runtime_type = ""

        [plugins."io.containerd.grpc.v1.cri".containerd.untrusted_workload_runtime.options]

    [plugins."io.containerd.grpc.v1.cri".image_decryption]
      key_model = "node"

    [plugins."io.containerd.grpc.v1.cri".registry]
      config_path = ""

      [plugins."io.containerd.grpc.v1.cri".registry.auths]

      [plugins."io.containerd.grpc.v1.cri".registry.configs]

      [plugins."io.containerd.grpc.v1.cri".registry.headers]

      [plugins."io.containerd.grpc.v1.cri".registry.mirrors]

    [plugins."io.containerd.grpc.v1.cri".x509_key_pair_streaming]
      tls_cert_file = ""
      tls_key_file = ""

  [plugins."io.containerd.internal.v1.opt"]
    path = "/opt/containerd"

  [plugins."io.containerd.internal.v1.restart"]
    interval = "10s"

  [plugins."io.containerd.internal.v1.tracing"]
    sampling_ratio = 1.0
    service_name = "containerd"

  [plugins."io.containerd.metadata.v1.bolt"]
    content_sharing_policy = "shared"

  [plugins."io.containerd.monitor.v1.cgroups"]
    no_prometheus = false

  [plugins."io.containerd.runtime.v1.linux"]
    no_shim = false
    runtime = "runc"
    runtime_root = ""
    shim = "containerd-shim"
    shim_debug = false

  [plugins."io.containerd.runtime.v2.task"]
    platforms = ["linux/amd64"]
    sched_core = false

  [plugins."io.containerd.service.v1.diff-service"]
    default = ["walking"]

  [plugins."io.containerd.service.v1.tasks-service"]
    rdt_config_file = ""

  [plugins."io.containerd.snapshotter.v1.aufs"]
    root_path = ""

  [plugins."io.containerd.snapshotter.v1.btrfs"]
    root_path = ""

  [plugins."io.containerd.snapshotter.v1.devmapper"]
    async_remove = false
    base_image_size = ""
    discard_blocks = false
    fs_options = ""
    fs_type = ""
    pool_name = ""
    root_path = ""

  [plugins."io.containerd.snapshotter.v1.native"]
    root_path = ""

  [plugins."io.containerd.snapshotter.v1.overlayfs"]
    mount_options = []
    root_path = ""
    sync_remove = false
    upperdir_label = false

  [plugins."io.containerd.snapshotter.v1.zfs"]
    root_path = ""

  [plugins."io.containerd.tracing.processor.v1.otlp"]
    endpoint = ""
    insecure = false
    protocol = ""

[proxy_plugins]

[stream_processors]

  [stream_processors."io.containerd.ocicrypt.decoder.v1.tar"]
    accepts = ["application/vnd.oci.image.layer.v1.tar+encrypted"]
    args = ["--decryption-keys-path", "/etc/containerd/ocicrypt/keys"]
    env = ["OCICRYPT_KEYPROVIDER_CONFIG=/etc/containerd/ocicrypt/ocicrypt_keyprovider.conf"]
    path = "ctd-decoder"
    returns = "application/vnd.oci.image.layer.v1.tar"

  [stream_processors."io.containerd.ocicrypt.decoder.v1.tar.gzip"]
    accepts = ["application/vnd.oci.image.layer.v1.tar+gzip+encrypted"]
    args = ["--decryption-keys-path", "/etc/containerd/ocicrypt/keys"]
    env = ["OCICRYPT_KEYPROVIDER_CONFIG=/etc/containerd/ocicrypt/ocicrypt_keyprovider.conf"]
    path = "ctd-decoder"
    returns = "application/vnd.oci.image.layer.v1.tar+gzip"

[timeouts]
  "io.containerd.timeout.bolt.open" = "0s"
  "io.containerd.timeout.shim.cleanup" = "5s"
  "io.containerd.timeout.shim.load" = "5s"
  "io.containerd.timeout.shim.shutdown" = "3s"
  "io.containerd.timeout.task.state" = "2s"

[ttrpc]
  address = ""
  gid = 0
  uid = 0

启动containerd

1
systemctl enable --now containerd

安装nerdctl工具

ctr和crictl都只能用于debug, 不能打tag, nerdctl 可以,
详见: https://github.com/containerd/containerd/blob/main/docs/getting-started.md#interacting-with-containerd-via-cli
git hub地址: https://github.com/containerd/nerdctl

1
2
3
4
5
6
7
8
mkdir  -p /data/src
cd /data/src
wget https://github.com/containerd/nerdctl/releases/download/v1.7.2/nerdctl-1.7.2-linux-amd64.tar.gz
mkdir -p nerdctl-1.7.2
tar zxvf nerdctl-1.7.2-linux-amd64.tar.gz -C nerdctl-1.7.2

cp nerdctl-1.7.2/*  /usr/sbin/

部署k8s

kubeadm初始化配置

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
# 打印默认的init信息并保存.
mkdir -p /data/k8s/init-install
cd /data/k8s/init-install
kubeadm config print init-defaults > kubeadm.yaml

# 修改信息如下:
[root@control-plane init-install]# cat kubeadm.yaml
apiVersion: kubeadm.k8s.io/v1beta3
bootstrapTokens:
- groups:
  - system:bootstrappers:kubeadm:default-node-token
  token: abcdef.0123456789abcdef
  ttl: 24h0m0s
  usages:
  - signing
  - authentication
kind: InitConfiguration
localAPIEndpoint:
  advertiseAddress: 192.168.1.237          # 修改为控制平面IP
  bindPort: 6443
nodeRegistration:
  criSocket: unix:///var/run/containerd/containerd.sock  # containerd的sock
  #criSocket: unix:///var/run/cri-dockerd.sock    # 修改为cri-dockerd的sock
  imagePullPolicy: IfNotPresent
  name: control-plane          # node修改为control-plane
  taints:
---
apiServer:
  timeoutForControlPlane: 4m0s
apiVersion: kubeadm.k8s.io/v1beta3
certificatesDir: /etc/kubernetes/pki
clusterName: kubernetes
controllerManager: {}
dns: {}
etcd:
  local:
    dataDir: /var/lib/etcd
#imageRepository: registry.k8s.io
imageRepository: registry.cn-shenzhen.aliyuncs.com/only_wild_weeds        # 修改为自己的镜像源
kind: ClusterConfiguration
kubernetesVersion: 1.29.0                  # kubeadm是1.29.0, 输出安装的版本就不用改了, 如果需要改,
# 参考
# - Kubernetes [版本与版本间的偏差策略](https://kubernetes.io/zh-cn/releases/version-skew-policy/)
# - kubeadm 特定的[版本偏差策略](https://kubernetes.io/zh-cn/docs/setup/production-environment/tools/kubeadm/create-cluster-kubeadm/#version-skew-policy)
networking:
  dnsDomain: cluster.local
  serviceSubnet: 10.96.0.0/12
  podSubnet: 10.244.0.0/16 # 指定pod的IP地址.
scheduler: {}
#### 配置kube-proxy 模式,
# 参考: https://github.com/kubernetes/kubernetes/blob/master/pkg/proxy/ipvs/README.md#run-kube-proxy-in-ipvs-mode
---
apiVersion: kubeproxy.config.k8s.io/v1alpha1
kind: KubeProxyConfiguration
mode: ipvs

下载初始化需要的镜像

1
2
3

kubeadm config images pull --image-repository=registry.cn-shenzhen.aliyuncs.com/only_wild_weeds  --kubernetes-version=1.29.0

部署

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56

# 使用生成的配置文件初始化(默认是找/var/lib/kubelet/config.yaml)
kubeadm init --config /data/k8s/init-install/kubeadm.yaml

# 如下输出

[bootstrap-token] Creating the "cluster-info" ConfigMap in the "kube-public" namespace
[kubelet-finalize] Updating "/etc/kubernetes/kubelet.conf" to point to a rotatable kubelet client certificate and key
[addons] Applied essential addon: CoreDNS
[addons] Applied essential addon: kube-proxy

Your Kubernetes control-plane has initialized successfully!

To start using your cluster, you need to run the following as a regular user:

  mkdir -p $HOME/.kube
  sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
  sudo chown $(id -u):$(id -g) $HOME/.kube/config

Alternatively, if you are the root user, you can run:

  export KUBECONFIG=/etc/kubernetes/admin.conf

You should now deploy a pod network to the cluster.
Run "kubectl apply -f [podnetwork].yaml" with one of the options listed at:
  https://kubernetes.io/docs/concepts/cluster-administration/addons/

Then you can join any number of worker nodes by running the following on each as root:

kubeadm join 192.168.126.128:6443 --token abcdef.0123456789abcdef \
	--discovery-token-ca-cert-hash sha256:2228e98b56d218ead25d8d54173148c312dcd911f9be77eac9e768d095f8446e


# 按提示的操作输出
mkdir -p $HOME/.kube
sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
sudo chown $(id -u):$(id -g) $HOME/.kube/config

# 查看node, 可以看到CRI是 containerd://1.6.26
[root@control-plane init-install]# kubectl get no -o wide
NAME            STATUS     ROLES           AGE   VERSION   INTERNAL-IP       EXTERNAL-IP   OS-IMAGE                KERNEL-VERSION                 CONTAINER-RUNTIME
control-plane   NotReady   control-plane   19s   v1.29.0   192.168.126.128   <none>        CentOS Linux 7 (Core)   3.10.0-1160.105.1.el7.x86_64   containerd://1.6.26


# 查看pod, coredns在Pending, 因为等待 ready
[root@control-plane flannel]# kubectl get po --all-namespaces
NAMESPACE     NAME                             READY   STATUS    RESTARTS   AGE
kube-system   coredns-76cdc8f664-gwh49         0/1     Pending   0          58s
kube-system   coredns-76cdc8f664-sx7wl         0/1     Pending   0          58s
kube-system   etcd-control-plane                      1/1     Running   3          71s
kube-system   kube-apiserver-control-plane            1/1     Running   3          73s
kube-system   kube-controller-manager-control-plane   1/1     Running   4          72s
kube-system   kube-proxy-x5r56                 1/1     Running   0          58s
kube-system   kube-scheduler-control-plane            1/1     Running   4          71s


去掉control-plane的污点

1
2
3
4
# 默认情况下，出于安全原因，你的集群不会在控制平面节点上调度 Pod。
# 如果你希望能够在单机 Kubernetes 集群等控制平面节点上调度 Pod，请运行：
kubectl taint nodes --all node-role.kubernetes.io/control-plane-

卸载reset

1
2
3
4
5
6
7
8
# kubeadm reset -f --cri-socket=unix:///var/run/cri-dockerd.sock
# kubeadm reset -f --cri-socket=unix:///var/run/containerd/containerd.sock

iptables -F && iptables -t nat -F && iptables -t mangle -F && iptables -X
ipvsadm -C
rm -rf /etc/cni/net.d $HOME/.kube/config

systemctl restart kubelet

CNI部署后检查信息

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
[root@control-plane calico]# kubectl get no -o wide
NAME            STATUS   ROLES           AGE    VERSION   INTERNAL-IP     EXTERNAL-IP   OS-IMAGE                KERNEL-VERSION                CONTAINER-RUNTIME
control-plane   Ready    control-plane   142m   v1.29.0   192.168.1.237   <none>        CentOS Linux 7 (Core)   3.10.0-1160.45.1.el7.x86_64   containerd://1.6.26
[root@control-plane calico]#
[root@control-plane calico]#
[root@control-plane calico]# kubectl get po --all-namespaces
NAMESPACE          NAME                                       READY   STATUS    RESTARTS        AGE
calico-apiserver   calico-apiserver-85d58d95cd-8vr85          1/1     Running   2               140m
calico-apiserver   calico-apiserver-85d58d95cd-mw8bv          1/1     Running   2 (9m59s ago)   140m
calico-system      calico-kube-controllers-55c78f4978-4pg2k   1/1     Running   2               141m
calico-system      calico-node-bxc2l                          1/1     Running   2 (9m58s ago)   141m
calico-system      calico-typha-74844b875c-qjvzw              1/1     Running   2 (9m57s ago)   141m
calico-system      csi-node-driver-xchcd                      2/2     Running   4 (9m57s ago)   141m
kube-system        coredns-76cdc8f664-8tkck                   1/1     Running   2               142m
kube-system        coredns-76cdc8f664-r7pgh                   1/1     Running   2               142m
kube-system        etcd-control-plane                         1/1     Running   6 (9m57s ago)   142m
kube-system        kube-apiserver-control-plane               1/1     Running   2 (9m58s ago)   142m
kube-system        kube-controller-manager-control-plane      1/1     Running   2 (9m58s ago)   142m
kube-system        kube-proxy-6s7mv                           1/1     Running   2 (9m59s ago)   142m
kube-system        kube-scheduler-control-plane               1/1     Running   2 (9m58s ago)   142m
tigera-operator    tigera-operator-55585899bf-6d7qm           1/1     Running   2 (9m59s ago)   141m
[root@control-plane calico]#

[root@control-plane calico]# crictl images
IMAGE                                                                       TAG                 IMAGE ID            SIZE
docker.io/calico/apiserver                                                  v3.27.0             848c5b919e8d3       40.3MB
docker.io/calico/cni                                                        v3.27.0             8e8d96a874c0e       94.7MB
docker.io/calico/csi                                                        v3.27.0             91c1c91da7602       8.74MB
docker.io/calico/kube-controllers                                           v3.27.0             4e87edec0297d       33.3MB
docker.io/calico/node-driver-registrar                                      v3.27.0             d36ef67f7b24c       11.2MB
docker.io/calico/node                                                       v3.27.0             1843802b91be8       117MB
docker.io/calico/pod2daemon-flexvol                                         v3.27.0             6506d2e0be2d5       7.59MB
docker.io/calico/typha                                                      v3.27.0             b33768e0da1f8       29.6MB
docker.io/flannel/flannel-cni-plugin                                        v1.2.0              a55d1bad692b7       3.88MB
docker.io/flannel/flannel                                                   v0.24.0             0dc86fe0f22e6       28MB
quay.io/tigera/operator                                                     v1.32.3             7bc79e0d3be4f       21.4MB
registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/coredns                   v1.11.1             cbb01a7bd410d       18.2MB
registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/etcd                      3.5.10-0            a0eed15eed449       56.5MB
registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/kube-apiserver            v1.29.0             1443a367b16d3       35.1MB
registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/kube-controller-manager   v1.29.0             0824682bcdc8e       33.4MB
registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/kube-proxy                v1.29.0             98262743b26f9       28.4MB
registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/kube-scheduler            v1.29.0             7ace497ddb8e8       18.5MB
registry.cn-shenzhen.aliyuncs.com/only_wild_weeds/pause                     3.9                 e6f1816883972       319kB

安装k9s

github地址: https://github.com/derailed/k9s

1
rpm -ivh https://github.com/derailed/k9s/releases/download/v0.30.7/k9s_linux_amd64.rpm

安装网络插件

https://kubernetes.io/docs/concepts/cluster-administration/addons/

常见开源网络插件(2024-01-03) watch star fork 备注
flannel 245 8.3k 2.9k 不支持NetworkPolicy
calico 106 5.2k 1.2k
cilium 252 17.5k 2.6k 这个星最多, 但是内核要求4.9+
Weave Net 242 6.5k 670
kube-router 54 2.2k 462
romana 16 246 38

calico

calico 支持网络策略
https://docs.tigera.io/calico/latest/getting-started/kubernetes/quickstart

部署calico

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
mkdir -p /data/k8s/init-install/cni/calico
cd /data/k8s/init-install/cni/calico

# 安装 Tigera Calico 操作员和自定义资源定义。
wget https://raw.githubusercontent.com/projectcalico/calico/v3.27.0/manifests/tigera-operator.yaml
kubectl create -f  tigera-operator.yaml

# 通过创建必要的自定义资源来安装 Calico。有关此清单中可用配置选项的更多信息，请参阅[安装参考](https://docs.tigera.io/calico/latest/reference/installation/api)
wget https://raw.githubusercontent.com/projectcalico/calico/v3.27.0/manifests/custom-resources.yaml

# 修改custom-resources.yaml中的网段, 保持和kubeadm.conf中的 podSubnet: 10.244.0.0/16 一致
sed -i 's#192.168.0.0#10.244.0.0#g' custom-resources.yaml
kubectl create -f custom-resources.yaml

# 确保资源正常运行, 下载镜像时间要蛮久的, 家里网络花了14m,
watch kubectl get pods -n calico-system -o wide

# 卸载网络插件后要删除/etc/cni/net.d/下的文件, 避免冲突
kubectl delete -f custom-resources.yaml
kubectl delete -f tigera-operator.yaml
rm -rf /etc/cni/net.d/10-calico.conflist
rm -rf /etc/cni/net.d/10-kuberouter.conflist
rm -rf /etc/cni/net.d/calico-kubeconfig


安装配置calicoctl

https://docs.tigera.io/calico/latest/operations/calicoctl/install

1
2
3
4
5
6
7
8
9
10
11
# 下载安装
curl -L https://github.com/projectcalico/calico/releases/download/v3.27.0/calicoctl-linux-amd64 -o /usr/sbin/calicoctl

# 给执行权限
chmod +x /usr/sbin/calicoctl

# k8s命令行
# https://docs.tigera.io/calico/latest/operations/calicoctl/configure/kdd
DATASTORE_TYPE=kubernetes KUBECONFIG=~/.kube/config calicoctl get nodes

# 更多命令:  https://docs.tigera.io/calico/latest/reference/calicoctl/

Flannel

flannel 不支持网络策略
https://github.com/flannel-io/flannel#deploying-flannel-manually

1
2
3
4
mkdir -p /data/k8s/init-install/cni/flannel
cd /data/k8s/init-install/cni/flannel
wget https://github.com/flannel-io/flannel/releases/latest/download/kube-flannel.yml
kubectl apply -f kube-flannel.yml
